Features

• Hot-swappable 700-watts or 1500-watts power modules available in 48-, 24- or 12-volt outputs provides up to 12,000 watts of output power in a 2U package
• Available in four configurations to accommodate either four, five, seven or eight 700-watts or 1500-watts power modules, integrated with battery management and load distribution modules
• Integrated TCP/IP Ethernet communications for remote power monitoring and control
• Network security protocols include HTTPS, TLS 1.3, SNMP v1/v2c/v3
• Battery Management Module includes dual 100-amp battery breakers and low voltage disconnect relay, with features including battery state of charge reporting, runtime remaining, equalization charging and battery discharge testing
• Load Distribution Module available with four fully managed outputs (up to 12 managed outputs available)
• Alarm reporting via text or email notification
• Support for lead-acid and lithium-ion battery types
• Two-year warranty

Benefits

• Configurable DC power system provides flexibility and scalability to meet application requirements
• Reduce total cost of ownership by reducing site visits and maintenance costs due to remote monitoring and control functionality
• Improve the quality of service and uptime of your network by quickly resolving power issues remotely
• User-scheduled battery testing proactively alerts users when a connected backup battery is not holding charge
• Real-time reporting on battery state of charge, battery run-time remaining, and battery voltage levels
• Remotely monitor and toggle power to individually connected load devices utilizing load distribution module
• All connection points are external, allowing for quick and easy installation
• No additional software required as monitoring and control is provided via an onboard web-baser server

Please fill out the form for the model you are interested in, and we will contact you as soon as possible!
